Electric data
Process pressure –1 … 64 bar
Process temperature –40 … +100 °C (optional +150 °C)
Fill material density From 0.7 g/cm³
Viscosity 0.1 … 10000 mPas
Material, in contact with medium 1.4404 (optional Ra < 0.8 μm)
Material, housing 1.4404, plastic PEI
Response time 500 ms
Approval Overfi ll protection according to WHG
Process connection G ¾”, G1”, Triclamp 1”, Triclamp 2”, pipe connection DIN 11851 DN 25, 40, 50
Accuracy ± 2 mm
Reproducibility ± 1 mm
Hysteresis Switching output 2 mm
Temperature drift 0.03 mm/K
Ambient temperature Operation –40 … +70 °C
Ambient temperature Storage –40 … +80 °C
Enclosure rating M12 connection IP 67, DIN 43650 plug IP 65
Electronic (Version T) Electronic (Version C)
Switching output
Signal voltage HIGH UV – 3 V
Signal voltage LOW 0 V ± 1 V
Output current IA < 250 mA < 250 mA
Output load
Capacitive load 100 nF 100 nF
Inductive load 1 H 1 H
Supply voltage 10 … 55 V DC 20 … 253 V UC
Residual ripple ≤ 5 VPP
Current consumption < 10 mA < 4.2 mA
