Detection area from ... to 0 ... 50 mm
Teach-in
Electrical configuration DC 4-wire
Supply voltage Vs DC 12 ... 30 V
Ripple Upp ≤ 10 %
Voltage drop Ud ≤ 2.2 V
Power consumption ≤ 15 mA1)
Continuous current Ia ≤ 100 mA
Hysteresis H, of sr 4 mm
Repeatability R ≤ 0.1 mT (Ub and Ta constant)
EMC According to EN 60947-5-2
Switching output PNP
Output function Normally open
Connection type Cable with plug, M8, 4-pin, PUR, 0.3 m
Cable with plug, M12, 3-pin, PUR, 0.3 m
Cable with plug, M8, 4-pin,
w. knurled screws, PUR, 0.5 m
Cable, PUR, 2 m
Enclosure rating IP 672)
Wire-break protection
Short-circuit protection 3)
Reverse polarity protection
Power-up pulse suppression
Shock/vibration stress 30 g, 11 ms/10 ... 55 Hz, 1 mm
Ambient temperature Ta -20 °C ... +75 °C
Housing material Plastic
1) without load 2) according to EN 60529
