ÜRÜN ÖZELLİKLERİ
KATALOG - DR SERİSİ KATALOG - DRP SERİSİ
Universal AC giriş / Tam skala
(DR-120 anahtar ile AC giriş seçimli)
Korumalar: Kısa devre, aşırı yük, aşırı voltaj
Aşırı sıcaklık koruması (DR-100 dahil değildir)
DIN Ray montajı, TS35/7.5 yada 15
Serbest hava akışı soğutmalı
LED çıkış durum göstergesi
%100 tam yük testi
2 yıl garanti
ÜRÜN KODU BESLEME GERİLİMİ ÇIKIŞ EBATLAR
15W DR SERİSİ
DR-15-5 85-264 VAC 120-370 VDC 5VDC 2.4A 25 x 93 x 56mm
DR-15-12 85-264 VAC 120-370 VDC 12VDC 1.25A 25 x 93 x 56mm
DR-15-15 85-264 VAC 120-370 VDC 15VDC 1A 25 x 93 x 56mm
DR-15-24 85-264 VAC 120-370 VDC 24VDC 0.63A 25 x 93 x 56mm
30W DR SERİSİ
DR-30-5 85-264VAC 120-370VDC 5VDC
3A
78 x 93 x 56mm
DR-30-12 85-264VAC 120-370VDC 12VDC 2A 78 x 93 x 56mm
DR-30-15 85-264VAC 120-370VDC 15VDC 2A 78 x 93 x 56mm
DR-30-24 85-264VAC 120-370VDC 24VDC 1.5A 78 x 93 x 56mm
45W DR SERİSİ
DR-45-5 85-264VAC 5VDC 5A 78 x 93 x 67 mm
DR-45-12 85-264VAC 12VDC 3.5A 78 x 93 x 67 mm
DR-45-15 85-264VAC 15VDC 2.8A 78 x 93 x 67 mm
DR-45-24 85-264VAC 24VDC 2A 78 x 93 x 67 mm
60W DR SERİSİ
DR-60-5 88-264AC & 124-370VAC 5VDC 6.5A 199 x 110 x 50 mm
DR-60-12 88-132VAC & 176-264VAC 12VDC 4.5A 199 x 110 x 50 mm
DR-60-15 88-132VAC & 176-264VAC 15VDC 4A 199 x 110 x 50 mm
DR-60-24 88-132VAC & 176-264VAC 24VDC 2.5 199 x 110 x 50 mm
100W DR SERİSİ
DR-100-12 85-264VAC 120-370VDC 5VDC 40A 199 x 99 x 50 mm
DR-100-15 85-264VAC 120-370VDC 12VDC 16.7A 199 x 99 x 50 mm
DR-100-24 85-264VAC 120-370VDC 15VDC 13.4A 199 x 99 x 50 mm
75W DR SERİSİ
DR-75-12 85-264VAC 12VDC 6.3A 55.5 x 125.2 x 100 mm
DR-75-24 85-264VAC 12VDC 3.2A 55.5 x 125.2 x 100 mm
DR-75-48 85-264VAC 15VDC 1.6A 55.5 x 125.2 x 100 mm
120W DR SERİSİ
DR-120-12 90-132VAC & 180-264VAC 12VDC 10A 65.5 x 125.2 x 100 mm
DR-120-24 90-132VAC & 180-264VAC 15VDC 5A 65.5 x 125.2 x 100 mm
DR-120-48 90-132VAC & 180-264VAC 24VDC 2.5A 65.5 x 125.2 x 100 mm
240W DRP SERİSİ
DRP-240-24 85-264VAC 24VDC 10A 125.5 x 125.2 x 100 mm
DRP-240-48 85-264VAC 48VDC 5A 125.5 x 125.2 x 100 mm
480W DRP SERİSİ
DRP-480-24 180-264VAC 24VDC 20A 227 x 125.2 x 100 mm
DRP-480-48 180-264VAC 48VDC 10A 227 x 125.2 x 100 mm
DR-RD20 SERİSİ
DR-RD20 24-28VDC 24-28VDC 20A 55 x 125.2 x 100 mm
DR-UPS40 SERİSİ
DR-UPS40 24-29VDC 24-29VDC 40A 55 x 125.2 x 100 mm
