Beam spacing 2 mm
MDO/Resolution*
Detection height 50 mm
Number of beams 26
Scanning range 1) 0 ... 2 m
Synchronization Synchronization by wire Sync A/Sync B
Light source LED, infrared
Supply voltage VS 2) 15 ... 30 V DC
Residual ripple < 10 % within Vs tolerances
Current consumption sender < 100 mA
Current consumption receiver 3) < 100 mA
Connection M12 Plug, 8 pins
Switching output 4) PNP output: Q
_
& Q
NPN output: Q
_
& Q
Operating mode Q dark-switching, Q
_
light-switching
Output current IA max. 100 mA
Output load Capacitive load: 100 nF
Inductive load: 1 H
Test input “TE” Sender OFF: Test input to Vs
Response time 5) 3 ms
Initialisation duration after Power ON Max. 800 ms
High immunity to ambient light 50.000 lx
VDE protection class III
Circuit protection 6) A, B, C
Enclosure rating IP 54
Ambient temperature TA Operation –25 ... +55 °C
Storage –40 ... +70 °C
Mechanical resistance Vibration: 5 g/10-55 Hz - IEC 68-2-6
Shock: 10 g/ 16ms - IEC 68-2-29
Weight Approx. 135
