ÜRÜN ÖZELLİKLERİ
KATALOG - NES SERİSİ
Universal AC giriş / Tam skala
(NES/D-100, NES-150 anahtar ile AC giriş seçimli)
Korumalar: Kısa devre, aşırı yük, aşırı voltaj
Serbest hava akışı soğutmalı
Küçük boyutlu, yüksek güç yoğunluklu
%100 tam yük testi
2 yıl garanti
15W NES SERİSİ
ÜRÜN KODU BESLEME ÇIKIŞ EBAT
NES-15-5 85-264 VAC 120-370 VDC 5VDC 3A 78 x 51 x 28 mm
NES-15-12 85-264 VAC 120-370 VDC 12VDC 1.3A 78 x 51 x 28 mm
NES-15-15 85-264 VAC 120-370 VDC 15VDC 1A 78 x 51 x 28 mm
NES-15-24 85-264 VAC 120-370 VDC 24VDC 0.7A 78 x 51 x 28 mm
NES-15-48 85-264 VAC 120-370 VDC 48VDC 0.35A 78 x 51 x 28 mm
25W NES SERİSİ
NES-25-5 85-264 VAC 120-370 VDC 5VDC 5A 99 x 82 x 35 mm
NES-25-12 85-264 VAC 120-370 VDC 12VDC 2.1A 99 x 82 x 35 mm
NES-25-15 85-264 VAC 120-370 VDC 15VDC 1.7A 99 x 82 x 35 mm
NES-25-24 85-264 VAC 120-370 VDC 24VDC 1.1A 99 x 82 x 35 mm
NES-25-48 85-264 VAC 120-370 VDC 48VDC 0.5A 99 x 82 x 35 mm
50W NES SERİSİ
NES-50-5 85-264 VAC 120-370 VDC 5VDC 10A 129 x 98 x 38 mm
NES-50-12 85-264 VAC 120-370 VDC 12VDC 4.2A 129 x 98x 38 mm
NES-50-15 85-264 VAC 120-370 VDC 15VDC 3.4A 129 x 98 x 38 mm
NES-50-24 85-264 VAC 120-370 VDC 24VDC 2.2A 129 x 98 x 38 mm
NES-50-48 85-264 VAC 120-370 VDC 48VDC 1.1A 129 x 98 x 38 mm
100W NES SERİSİ
NES-100-5 115 & 230VAC 5VDC 20A 159 x 97 x 38 mm
NES-100-12 115 & 230VAC 12VDC 8.5A 159 x 97 x 38 mm
NES-100-15 115 & 230VAC 15VDC 7A 159 x 97 x 38 mm
NES-100-24 115 & 230VAC 24VDC 4.5A 159 x 97 x 38 mm
NES-100-48 115 & 230VAC 48VDC 2.3A 159 x 97 x 38 mm
150W NES SERİSİ
NES-150-5 115 & 230VAC 5VDC 26A 199 x 98 x 38 mm
NES-150-12 115 & 230VAC 12VDC 12.5A 199 x 98 x 38 mm
NES-150-15 115 & 230VAC 15VDC 10A 199 x 98 x 38 mm
NES-150-24 115 & 230VAC 24VDC 6.5A 199 x 98 x 38 mm
NES-150-48 115 & 230VAC 48VDC 3.5A 199 x 98 x 38 mm
200W NES SERİSİ
NES-200-5 90-132 VAC 180-264 VDC 5VDC 40A 215 x 115 x 50 mm
NES-200-12 90-132 VAC 180-264 VDC 12VDC 16.5A 215 x 115 x 50 mm
NES-200-15 90-132 VAC 180-264 VDC 15VDC 13.3A 215 x 115 x 50 mm
NES-200-24 90-132 VAC 180-264 VDC 24VDC 8.3A 215 x 115 x 50 mm
NES-200-48 90-132 VAC 180-264 VDC 48VDC 4.2A 215 x 115 x 50 mm
350W NES SERİSİ
NES-350-5 90-132 VAC 180-264 VDC 5VDC 60A 215 x 115 x 50 mm
NES-350-12 90-132 VAC 180-264 VDC 12VDC 29A 215 x 115 x 50 mm
NES-350-15 90-132 VAC 180-264 VDC 15VDC 23.2A 215 x 115 x 50 mm
NES-350-24 90-132 VAC 180-264 VDC 24VDC 14.6A 215 x 115 x 50 mm
NES-350-48 90-132 VAC 180-264 VDC 48VDC 7.3A 215 x 115 x 50 mm
Ebatlar (Boy x En x Yükseklik) mm.
& 110-220VAC Anahtar seçimini belirtir
