Scanning distance/scanning range 15 mm/60 mm
Light source1); light type; LED; green;
Wavelength (nm) 520
Light source1); light type; LED; red, green, blue;
Wavelength (nm) 640, 525, 470
Supply voltage VS 10... 30 V DC2)
Residual ripple3) < 5 VPP
Current consumption4) < 30 mA at DC 24 V
Switching outputs Light-/dark-switching, selectable
PNP: HIGH = VS – < 2 V/LOW = 0 V
NPN: HIGH = VS /LOW = < 2 V
Output current IA max. 100 mA short-circuit protected
Response time5); switching frequency6) 50 μs; 10000/s
Time delay No timing element
Deactivation delay, ... 20 ms
Analogue output QA 0.3 ... 10 mA
Connection type Plug M12, 4-pin
VDE protection class8) V
Enclosure rating IP 67
Ambient temperature TA Operation –10 ... +55 °C
Storage –25 ... +75 °C
Shock load To IEC 68
Weight Approx. 400 g
Housing Cast zinc
Switching threshold adjustment/ Manual switching threshold setting 9)
