Operating scanning distance 1) 13 ... 100 mm (150 mm)
(limiting scanning distance) 13 ... 150 mm (250 mm)
Ultrasonic frequency Approx. 380 kHz
Resolution 0.18 mm
Reproducibility ±0.15 % 2)
Temperature drift 0.17 %/K
≤ 2 % 2) 3)
Supply voltage Vs 20 ... 30 V DC
Residual ripple 10 %
Current consumption ≤ 25 mA
Switching output 4) q, Q: PNP
q, Q: NPN
Response time 5) 26 ms
Switching frequency 20/s
Switching hysteresis 2.0 mm
Standby delay < 300 ms
Indicator Two LED green/yellow
Control element(s) Teach-in button
Connection type Plug M8, 3-pin
VDE protection class
Temperature compensation Yes
Enclosure rating IP 67
Ambient temperature Operation –20 °C ... +70 °C
Storage –40 °C ... +85 °C
Weight Approx. 10 g
Housing material 6) ABS plastic
