ÜRÜN ÖZELLİKLERİ
KATALOG - NET SERİSİ KATALOG - T SERİSİ
Universal AC giriş / Tam skala
Korumalar: Kısa devre, aşırı yük, aşırı voltaj
Serbest hava akışı soğutmalı
Küçük boyutlu, yüksek güç yoğunluklu
%100 tam yük testi
2 yıl garanti
ÜRÜN KODU BESLEME GERİLİMİ ÇIKIŞ 1 ÇIKIŞ 2 ÇIKIŞ 3 EBATLAR
35W NET SERİSİ
NET-35A 85-260 VAC 120-370 VDC 5VDC 4A 12VDC 1.5A -5VDC 0.5A 99 x 97 x 36 mm
NET-35B 85-260 VAC 120-370 VDC 5VDC 4A 12VDC 1.5A -12VDC 0.5A 99 x 97 x 36 mm
NET-35C 85-260 VAC 120-370 VDC 5VDC 3.5A 15VDC 1.5A -15VDC 0.5A 99 x 97 x 36 mm
NET-35D 85-260 VAC 120-370 VDC 5VDC 3.5A 24VDC 1A 12VDC 1A 99 x 97 x 36 mm
50W NET SERİSİ
NET-50A 85-264VAC 120-370VDC 5VDC 5A 12VDC 2.5A -5VDC 0.7A 129 x 98 x 38 mm
NET-50B 85-264VAC 120-370VDC 5VDC 5A 12VDC 2.5A -12VDC 0.7A 129 x 98 x 38 mm
NET-50C 85-264VAC 120-370VDC 5VDC 5A 15VDC 5A -15VDC 0.7A 129 x 98 x 38 mm
NET-50D 85-264VAC 120-370VDC 5VDC 5A 24VDC 1.5A 12VDC 1.5A 129 x 98 x 38 mm
75W NET SERİSİ
NET-75A 85-264VAC 120-370VDC 5VDC 7A 12VDC 3.5A -5VDC 0.7A 159 x 97 x 38 mm
NET-75B 85-264VAC 120-370VDC 5VDC 7A 12VDC 3.5A -12VDC 0.7A 159 x 97 x 38 mm
NET-75C 85-264VAC 120-370VDC 5VDC 7A 15VDC 3.5A -15VDC 0.7A 159 x 97 x 38 mm
NET-75D 85-264VAC 120-370VDC 5VDC 6A 24VDC 2A 12VDC 1A 159 x 97 x 38 mm
60W T SERİSİ
T-60A 85-264VAC 120-370VDC 5VDC 7A 12VDC 3.5A -5VDC 1A 159 x 97 x 38 mm
T-60B 85-264VAC 120-370VDC 5VDC 7A 12VDC 3.5A -12VDC 1A 159 x 97 x 38 mm
T-60C 85-264VAC 120-370VDC 5VDC 7A 15VDC 3A -15VDC 1A 159 x 97 x 38 mm
120W T SERİSİ
T-120A 88-132VAC 176-264VAC 5VDC 12A 12VDC 5A -5VDC 1A 119 x 110 x 50 mm
T-120B 88-132VAC 176-264VAC 5VDC 12A 12VDC 5A -12VDC 1A 119 x 110 x 50 mm
T-120C 88-132VAC 176-264VAC 5VDC 12A 15VDC 5A -15VDC 1A 119 x 110 x 50 mm
T-120D 88-132VAC 176-264VAC 5VDC 12A 12VDC 5A 24VDC 2A 119 x 110 x 50 mm
Ebatlar (Boy x En x Yükseklik) mm
& 110-220VAC Anahtar seçimi
