Fork width 3 mm
Minimum detectable object size 1)
Gap between labels 2 mm
Size of labels 2 mm
Supply voltage VS 10 ... 30 V DC 2)
Current consumption 3) 40 mA
Ripple (at 10 mA) 4) < 1 V
Switching output PNP and NPN
Light/dark adjustable via button
Signal voltage
PNP HIGH = UV – (< 2 V)/LOW = 0 V
NPN HIGH = UV/LOW = < 2 V
Output current IA 100 mA
Capacitive load 200 nF
Response time 5) 300 μs
Initialisation time 100 ms
VDE protection class 6) III
Enclosure rating IP 65
Circuit protection 7) B, C
Short-circuit protection ✔
Ambient temperature Operation +5 °C ... +55 °C
Storage –30 °C ... +70 °C
Operating principle: fork Ultrasonic detection principle
Air movement 5 m/sec. max. wind speed
Connection type M8, 4-pin
Adjustment option “+”, “–” adjustment via button
