TEKNiK ÖZELLiKLER
Fork width 2 mm
5 mm
15 mm
30 mm
50 mm
80 mm
120 mm
Fork depth 40, 60 or 95 mm
Light source Laser, modulated, 670 nm, class 1
Minimum detectable object size 0.05 mm
Supply voltage VS 10 ... 30 V DC 2)
Current consumption 3) 40 mA
Residual ripple 4) < 10 %
Switching output PNP and NPN
Light/dark adjustable via button
Signal voltage
PNP HIGH = VS – (< 2 V)/LOW = 0 V
NPN HIGH = VS/LOW = < 2 V
Output current IA 100 mA
Stability of response time 5) ± 20 μs
Response time 5), switching frequency 6) Max. 100 μs; 10,000/s
Teach-in via button
Initialisation time 100 ms
Ambient light safety
Incandescent lamp 5,000 Lux
Sunlight 10,000 Lux
VDE protection class 7)
Enclosure rating IP 65
Circuit protection 8) A, B, C
Ambient temperature 9) Operation –20 °C ... +50 °C
Storage –30 °C ... +80 °C
