ÜRÜN ÖZELLİKLERİ
KATALOG - PSP SERİSİ KATALOG - SP SERİSİ KATALOG - RSP SERİSİ
Universal AC giriş / Tam skala
Dahili aktif PFC fonksiyonu: PF>0.98 (@115VAC), PF>0.95 (@230VAC)
Korumalar: Kısa devre, aşırı yük, aşırı voltaj, aşırı sıcaklık
Dahili DC fan ile soğutma
Dahili uzaktan ON/OFF kontrolü ve çıkış voltaj algılama
DC OK sinyal çıkışı (PSP-1000/1500 serisi dahil değildir)
Paralel bağlanabilme özelliği (PSP-1500 serisi dahil değildir)
2 yıl garanti
ÜRÜN KODU BESLEME GERİLİMİ ÇIKIŞ EBATLAR
600W PSP SERIES
PSP-600-5 88-264 VAC 124-370 VDC 5VDC 80A 170 x 120 x 93 mm
PSP-600-12 88-264 VAC 124-370 VDC 12VDC 50A 170 x 120 x 93 mm
PSP-600-15 88-264 VAC 124-370 VDC 15VDC 40A 170 x 120 x 93 mm
PSP-600-24 88-264 VAC 124-370 VDC 24VDC 25A 170 x 120 x 93 mm
PSP-600-48 88-264 VAC 124-370 VDC 48VDC 12.5A 170 x 120 x 93 mm
750W SP SERIES
SP-750-5 90-264VAC 5VDC 120A 278 x 127 x 63.5 mm
SP-750-12 90-264VAC 12VDC 62.5A 278 x 127 x 63.5 mm
SP-750-15 90-264VAC 15VDC 50A 278 x 127 x 63.5 mm
SP-750-24 90-264VAC 24VDC 31.3A 278 x 127 x 63.5 mm
SP-750-48 90-264VAC 48VDC 15.7A 278 x 127 x 63.5 mm
1000W RSP SERIES
RSP-1000-12 90-264 VAC 127-370 VDC 12VDC 60A 295 x 127 x 41 mm
RSP-1000-15 90-264 VAC 127-370 VDC 15VDC 50A 295 x 127 x 41 mm
RSP-1000-24
90-264 VAC 127-370 VDC 24VDC 40A 295 x 127 x 41 mm
RSP-1000-48 90-264 VAC 127-370 VDC 48VDC 21A 295 x 127 x 41 mm
1500W RSP SERIES
RSP-1500-5 90-264 VAC 127-370 VDC 5VDC 240A 278 x 127 x 83.5 mm
RSP-1500-12 90-264 VAC 127-370 VDC 12VDC 125A 278 x 127 x 83.5 mm
RSP-1500-15 90-264 VAC 127-370 VDC 15VDC 100A 278 x 127 x 83.5 mm
RSP-1500-24 90-264 VAC 127-370 VDC 24VDC 63A 278 x 127 x 83.5 mm
RSP-1500-48 90-264 VAC 127-370 VDC 48VDC 32A 278 x 127 x 83.5 mm
2400W RSP SERIES
RSP-2400-12 180-264 VAC 254-370 VDC 12VDC 166.7A 278 x 177.8 x 63.5 mm
RSP-2400-24 180-264 VAC 254-370 VDC 24VDC 100A 278 x 177.8 x 63.5 mm
RSP-2400-48 180-264 VAC 254-370 VDC 48VDC 50A 278 x 177.8 x 63.5 mm
3000W RSP SERIES
RSP-3000-12 180-264 VAC 254-370 VDC 12VDC 200A 278 x 177.8 x 63.5 mm
RSP-3000-24 180-264 VAC 254-370 VDC 24VDC 125A 278 x 177.8 x 63.5 mm
RSP-3000-48 180-264 VAC 254-370 VDC 48VDC 62.5A 278 x 177.8 x 63.5 mm
